Appearance
Dimensions Double-sided 80.0 mm x 23.1 mm x 9.2 mm (3.15" x 0.9"x 0.36")
Weight 34 g (1.19 oz)
Type M.2 2280
Interface
Bus Interface NVMe PCIe Gen4 x4
Storage
Flash Type 3D NAND flash
Capacity 2 TB
Operating Environment
Operating Temperature 0°C (32°F) ~ 70°C (158°F)
Operating Voltage 3.3V±5%
Performance
Sequential Read/Write (CrystalDiskMark) up to 7,200/6,200 MB/s
4K Random Read/Write (IOmeter) up to 530,000/420,000 IOPS
Terabytes Written (TBW) 780 TBW
Mean Time Between Failures (MTBF) 3,000,000 hour(s)
Drive Writes Per Day (DWPD) 0.43 (5 yrs)
Warranty Five-year Limited Warranty
